DisplayMan’s 64-inch transparent Micro LED display combines two 42-inch panels into one 1920 × 1080 landscape canvas. Bring self-emissive, full-color content into retail presentations, exhibits and corporate showrooms while retaining a view through the display.
The supplied reference lists 70% transparency, with optional touch available at additional cost. Review the glass, integrated electronics base, mounting and playback system as one complete assembly.
64-Inch Transparent Micro LED
A Full HD transparent display formed from two 42-inch panels in a landscape assembly.
DisplayMan’s 64-inch configuration uses two 42-inch base panels side by side. Each contributes 960 × 1080 pixels, creating one 1920 × 1080 content canvas with a 16:9 aspect ratio.
Self-emissive Micro LED imagery appears on a transparent structure, allowing products, exhibits and the surrounding space to remain visible behind unused image regions. Design the digital content and physical background as one presentation.
The supplied reference lists 70% transparency. Review the complete assembly with the intended background lighting, content and viewing distance, particularly when adding optional touch or additional glass.
The 64-inch model belongs to the 42-inch platform family. It is a 2 × 1 assembly of 42-inch panels, separate from the configurations based on 16.1-inch panels.
Use 1920 × 1080 media and coordinate the controller mapping for one complete landscape presentation.
Review the glass support and integrated electronics base as a complete product. Fixing points, connectors and service space must follow the approved assembly drawing.
Built From the 42-Inch Base Panel
Two 960 × 1080 panels are arranged side by side to form the 1920 × 1080 canvas. Prepare content as one continuous image across the finished display.
| Display Size | 42-Inch Base-Panel Layout | Base Panels | Project Direction |
|---|---|---|---|
| 42 inch | 1 × 1 | 1 | Single base-panel presentation |
| 64 inch | 2 × 1 | 2 | Landscape Full HD assembly |
| 83 inch | 2 × 2 | 4 | Larger assembly based on the same 42-inch platform; confirm its separate model specification |
Choose content playback alone or add touch interaction at additional cost. Confirm the entire optical, mechanical and software configuration with the quotation.
Use Full HD animation, product imagery and concise messaging for retail, exhibits and corporate presentations.
Add touch for guided product exploration, exhibit navigation or branded interaction. Touch is an optional configuration supplied at additional cost.
Reference Model Specifications
Reference data from the supplied 64-inch Micro LED specification v2.0. Confirm the finished assembly and approved drawing before installation.
| Parameter | 64-Inch Reference |
|---|---|
| Reference model | T008 / 64-inch configuration |
| Panel configuration | Two 42-inch panels, side by side: 2 columns × 1 row |
| Resolution per base panel | 960 × 1080 |
| Combined native resolution | 1920 × 1080 (Full HD) |
| Display aspect ratio | 16:9, consistent with the resolution and active-area dimensions |
| Active display area (W × H) | 1405.44 × 790.56 mm, as marked AA in the reference drawing |
| Reference outline (W × H) | 1417.32 × 839.9 mm; confirm against the selected assembly drawing |
| Panel technology | Active-matrix LTPS-TFT glass |
| LED technology | RGB Micro LED flip chips |
| LED chip size | 20 × 40 µm |
| Transparency | 70%, reference value; complete optional-touch assembly to be confirmed |
| Maximum full-white brightness | 600 nits |
| Peak brightness | 1,200 nits |
| Color gamut | NTSC 120% / DCI-P3 98%, as listed in the reference |
| Viewing angle | 178° horizontal / 178° vertical |
| Contrast ratio | 1,000,000:1, reference value |
| Refresh rate | 120 Hz |
| Response time | Less than 1 ms |
| Panel power | 600 W, as listed; operating conditions and complete-system consumption to be confirmed |
| Supply | 100–240 VAC, 50/60 Hz |
| Protective glass | Front: 2 mm / rear: 1.1 mm |
| Glass assembly thickness | Less than 5 mm; not the total depth of the electronics base |
| Surface treatment | Anti-reflection / hard coating, 7H as listed in the reference |
| Reference weight | 10 kg, excluding video box |
| Operating temperature / humidity | 0–40°C / 10–80% |
| Signal / daisy-chain connectivity | HDMI / DisplayPort (daisy chain); controller scope and connection arrangement to be confirmed |
| Touch | Optional at additional cost |
| Housing depth, supports and fixing points | Confirm against the approved drawing for the selected configuration |
The reference drawing shows an electronics base attached along the bottom of the landscape assembly. Allow space for that housing, its connections and cable bends. The less-than-5-mm glass figure does not describe the complete base depth.
Application Directions
Review these indoor project directions around the final content, background, viewing distance and mounting structure.
Place digital product imagery in front of merchandise or a curated display background. Coordinate fixtures, screen placement and lighting.
Explore Related Direction →Add digital interpretation in front of exhibits while preserving a view through the screen. Review the display content and object lighting together.
Explore Related Direction →Present products, engineering stories and branded animation on a Full HD transparent canvas in a controlled interior.
Explore Related Direction →Add optional touch for guided product exploration or exhibit controls. Validate UI targets and viewing positions on the assembled screen.
Explore Related Direction →Evaluate a fixture-supported transparent presentation in reception, demonstration or sales spaces. Confirm the complete assembly scale and support method.
Explore Related Direction →Review custom fixture design, glass supports, controller access and software integration as one project before enclosure production.
Explore Related Direction →The reference drawing shows a landscape assembly with an attached bottom electronics base. Confirm mounting surfaces, load support, cable access and service space using the final drawing. Do not size fixtures using the glass thickness alone.
Prepare 1920 × 1080 content and confirm the supplied controller, input timing and mapping across both panels. The reference lists HDMI and DisplayPort daisy-chain connectivity; confirm how these are implemented in the quoted assembly.
Use the listed 600 W panel power as reference information, then confirm complete-system consumption and supply capacity. Review ventilation and the 0–40°C reference operating range before integrating the screen into furniture or an enclosure.
TRANSPARENT FAMILY
All Transparent Micro LED Displays →9.4-Inch Transparent Micro LED →
16.1-Inch Transparent Micro LED →
42-Inch Transparent Micro LED →
Transparent OLED Displays →
Transparent LCD Display Cabinets →
Transparent LCD Refrigerator Displays →
Transparent LCD Vending Displays →
Custom Touch Panels & Cover Glass →
Infrared Touch Frames →It combines two 42-inch base panels side by side in a 2 × 1 arrangement. Each panel contributes 960 × 1080 pixels, giving one 1920 × 1080 Full HD canvas.
No. The 64-inch configuration uses two 42-inch panels. The 20-, 30-, 54- and 60-inch configurations belong to the separate 16.1-inch-based family.
The supplied 64-inch specification lists 70% transparency. Confirm the complete optical assembly, particularly when adding touch or extra protective glass.
No. The specification lists 600 nits maximum full-white brightness and 1,200 nits peak. These values describe different image conditions.
Yes. Optional touch is available at additional cost. Confirm the touch frame, glass, host connection, operating system and software with the quotation.
The drawing marks an active area of 1405.44 × 790.56 mm and a reference outline of 1417.32 × 839.9 mm. Confirm the selected assembly, housing depth and fixing points against the final approved drawing.
No. The less-than-5-mm figure refers to the glass assembly. The attached electronics base requires additional depth and space for connections and cable routing.
The specification lists 600 W panel power and a 100–240 VAC, 50/60 Hz supply. It lists HDMI and DisplayPort daisy-chain connectivity. Confirm complete-system consumption and the supplied controller and connection arrangement.
The reference operating range is 0–40°C and 10–80% humidity. Full outdoor use requires a separate review of enclosure protection, condensation, temperature and mounting.
Provide the application, installation space, touch requirement, orientation, viewing distance, background lighting, playback source, sample and production quantities, destination and schedule.
Tell DisplayMan what the display needs to show, where it will be installed and whether visitors need touch interaction.
Please share your application, display size, quantity and project background. We will review the most practical display direction.
