The exhibition of Transparent OLED AI Digital Human Screens
Step into a new era of immersive technology with DisplayMan’s Transparent OLED AI Digital Human Screens, available in 30-inch, 55-inch, and 77-inch sizes. This exhibition showcases the perfect fusion of transparent OLED display and AI-powered virtual human interaction — bringing life to glass, and intelligence to space.
Visit the exhibition and witness how DisplayMan is redefining digital communication — one transparent screen at a time.
Category | Parameter Item | Details |
---|---|---|
Transparent Display | Display Size | 77 inches |
Transparent Display | Backlight Type | OLED |
Transparent Display | Display Resolution | 3840×2160 |
Transparent Display | Display Aspect Ratio | 16:9 |
Transparent Display | Brightness | 200 – 600cd/㎡, Auto – adjustment |
Transparent Display | Contrast Ratio | 200000:1 |
Transparent Display | Viewing Angle | 178°/178° |
Transparent Display | Response Time | 1ms (Gray To Gray) |
Transparent Display | Color Depth | 10bit (R:1.07 billion colors) |
Configuration System | Main Control | Windows Version (X86) |
Configuration System | CPU | I5 CPU |
Configuration System | Memory | 16G |
Configuration System | Storage | 512G |
Configuration System | Operating System | Windows 10 |
Touch Method | Capacitive Touch | 10 – point capacitive touch |
Power & Battery Params | Power Input (Charger) | AC 100 – 240V |
Power & Battery Params | Battery Voltage for Endurance | TBD |
Power & Battery Params | Battery Capacity for Endurance | TBD |
Power & Battery Params | Charging Method | TBD |
Power & Battery Params | Time for Full Charge | TBD |
Power & Battery Params | Battery Life | TBD |
Power & Battery Params | Overall Power Consumption | <600W |
Operating Environment | Running Time | 7×12h (Dynamic Playback) |
Operating Environment | Operating Temperature | 0℃ – 40℃ |
Operating Environment | Operating Humidity | 20% – 80% |
Structure | Material | Tempered Glass + Sheet Metal |
Structure | Overall Dimensions | 1972×1040×597(mm), see structure drawing |
Structure | Packing Dimensions | TBD |
Structure | Installation Method | Base – mounted |
Structure | Net Weight/Gross Weight | TBD |
Accessory List | – | Power Cord, Antenna, Remote Control, Certificate of Conformity & Warranty Card |
Miscellaneous | After – sales Service | One – year warranty |
Category | Parameter Item | Details |
---|---|---|
Transparent Display | Display Size | 55 inches |
Transparent Display | Backlight Type | OLED |
Transparent Display | Display Resolution | 1920×1080 |
Transparent Display | Display Aspect Ratio | 16:9 |
Transparent Display | Brightness | 200 – 600cd/㎡, Auto – adjustment |
Transparent Display | Contrast Ratio | 100000:1 |
Transparent Display | Viewing Angle | 178°/178° |
Transparent Display | Response Time | 0.1ms (Gray To Gray) |
Transparent Display | Color Depth | 10bit (R:1.07 billion colors) |
Configuration System | Main Control | Windows Version (X86) |
Configuration System | CPU | I5 CPU |
Configuration System | Memory | 16G |
Configuration System | Storage | 512G |
Configuration System | Operating System | Windows 10 |
Touch Method | Capacitive Touch | 10 – point capacitive touch |
Power & Battery Params | Power Input (Charger) | AC 220V |
Power & Battery Params | Battery Voltage for Endurance | 54.75±0.2V |
Power & Battery Params | Battery Capacity for Endurance | 48V 30Ah |
Power & Battery Params | Charging Method | Auto – recharge at low battery, or manual recharge command |
Power & Battery Params | Time for Full Charge | 5 hours |
Power & Battery Params | Battery Life | >2000 charge – discharge cycles |
Power & Battery Params | Overall Power Consumption | <200W |
Operating Environment | Running Time | 7×12h |
Operating Environment | Operating Temperature | 0℃ – 40℃ |
Operating Environment | Operating Humidity | 20% – 80% |
Structure | Material | Tempered Glass + Sheet Metal |
Structure | Overall Dimensions | 1860×832×570(mm), see structure drawing |
Structure | Packing Dimensions | TBD |
Structure | Installation Method | Base – mounted |
Structure | Net Weight/Gross Weight | TBD |
Accessory List | – | Power Cord, Remote Control, Certificate of Conformity & Warranty Card, Charger, Instruction Manual |
Miscellaneous | After – sales Service | One – year warranty |
Category | Parameter Item | Details |
---|---|---|
Transparent Display | Display Size | 30 inches |
Transparent Display | Backlight Type | OLED |
Transparent Display | Display Resolution | 1366×768 |
Transparent Display | Display Aspect Ratio | 16:9 |
Transparent Display | Brightness | 180 – 600cd/㎡, Auto – adjustment |
Transparent Display | Contrast Ratio | 135000:1 |
Transparent Display | Viewing Angle | 178°/178° |
Transparent Display | Response Time | 0.1ms (Gray To Gray) |
Transparent Display | Color Depth | 10bit (R:1.07 billion colors) |
Configuration System | Main Control | RK3568 |
Configuration System | CPU | Quad – core Cortex – A55, Max Frequency up to 2.0GHz |
Configuration System | Memory | 4G |
Configuration System | Storage | 32G |
Configuration System | Operating System | Android 11 |
Touch Method | Capacitive Touch | 10 – point capacitive touch |
Power & Battery Params | Power Input (Charger) | AC 220V |
Power & Battery Params | Battery Voltage for Endurance | 29.47V |
Power & Battery Params | Battery Capacity for Endurance | 25.6V 25Ah |
Power & Battery Params | Charging Method | Auto – recharge at low battery, or manual recharge command |
Power & Battery Params | Time for Full Charge | 5.5 hours |
Power & Battery Params | Battery Life | >2000 charge – discharge cycles |
Power & Battery Params | Overall Power Consumption | <150W |
Operating Environment | Running Time | 7×12h |
Operating Environment | Operating Temperature | 0℃ – 40℃ |
Operating Environment | Operating Humidity | 20% – 80% |
Structure | Material | Tempered Glass + Sheet Metal |
Structure | Overall Dimensions | 1750×500×500(mm), see structure drawing |
Structure | Packing Dimensions | TBD |
Structure | Installation Method | Base – mounted |
Structure | Net Weight/Gross Weight | 115KG/130KG |
Accessory List | – | Power Cord, Antenna, Remote Control, Certificate of Conformity & Warranty Card, Charger |
Miscellaneous | After – sales Service | One – year warranty |
